Configuring Network Settings
186 Check Point UTM-1 Edge User Guide
6. In the Mode drop-down list, select Enabled.
The fields are enabled.
7. In the IP Address field, type the IP address of the VLAN network's default
gateway.
Note: The VLAN network must not overlap other networks.
8. In the Subnet Mask field, type the VLAN's internal network range.
9. If desired, enable or disable Hide NAT.
See Enabling/Disabling Hide NAT on page
163.
10. If desired, configure a DHCP server.
See Configuring a DHCP Server on page
164.
11. Click Apply.
A warning message appears.
12. Click OK.
A success message appears.
13. Click Network in the main menu, and click the Ports tab.
The Ports page appears.
14. In the DMZ/WAN2 drop-down list, select VLAN Trunk.
15. Click Apply.
The DMZ/WAN2 port now operates as a VLAN Trunk port. In this mode, it will not
accept untagged packets.
16. Configure a VLAN trunk (802.1Q) port on the VLAN-aware switch, according
to the vendor instructions. Define the same VLAN IDs on the switch.
17. Connect the UTM-1 appliance's DMZ/WAN2 port to the VLAN-aware
switch's VLAN trunk port.
