308 Check Point UTM-1 Edge User Guide
The Save As dialog box appears.
c. Browse to a destination directory of your choice.
d. Type a name for the configuration file and click Save.
The *.xls file is created and saved to the specified directory.
5. To clear all displayed events:
a. Click Clear.
A confirmation message appears.
b. Click OK.
All events are cleared.
Using the Traffic Monitor
You can view incoming and outgoing traffic for selected network interfaces and QoS
classes using the Traffic Monitor. This enables you to identify network traffic trends and
anomalies, and to fine tune Traffic Shaper QoS class assignments.
The Traffic Monitor displays separate bar charts for incoming traffic and outgoing traffic,
and displays traffic rates in kilobits/second. If desired, you can change the number of
seconds represented by the bars in the charts, using the procedure Configuring Traffic
Monitor Settings on page
311.
In network traffic reports, the traffic is color-coded as described in the following table. In
the All QoS Classes report, the traffic is color-coded by QoS class.
Table 53: Traffic Monitor Color Coding for Networks
Traffic marked in this color… Indicates…
Blue VPN-encrypted traffic
Red Traffic blocked by the firewall
Green Traffic accepted by the firewall
