Sample Implementation on Two Gateways
250 Check Point UTM-1 Edge User Guide
In this field… Do this…
DMZ Type the amount to reduce the gateway's priority if the DMZ / WAN2
port's Ethernet link is lost.
This must be an integer between 0 and 255.
Advanced
Group ID If multiple HA clusters exist on the same network segment, type the ID
number of the cluster to which the gateway should belong.
This must be an integer between 1 and 255.
The default value is 55. If only one HA cluster exists, there is no need
to change this value.
Sample Implementation on Two Gateways
The following procedure illustrates how to configure HA for the following two UTM-1
gateways, Gateway A and Gateway B:
Table 46: Gateway Details
Gateway A Gateway B
Internal Networks LAN, DMZ LAN, DMZ
Internet Connections Primary and secondary Primary only
LAN Network IP Address 192.169.100.1 192.169.100.2
LAN Network
Subnet Mask
255.255.255.0 255.255.255.0
