Viewing ADSL Statistics
Chapter 11: Viewing Reports 321
2. To refresh the display, click Refresh.
Table 57: ADSL Statistics
This field… Displays…
Mode The ADSL connection's type (PPPoE, PPPoA, EoA)
Status The ADSL connection's current status (OK, Modem Initializing, No Sync,
Establishing Connection, Connected, Disabled)
DSL Standard The DSL line's standard
ADSL Annex The UTM-1 ADSL model (Annex A, Annex B)
Self Test Indicates whether DSL modem has passed a self-test
Trellis Coding The DSL line's trellis coding
Framing
Structure
The DSL line's framing structure
Line Rate The line rate for transmission (TX) and reception (RX) in kbps
ADSL
Firmware
The installed ADSL firmware
Tx Power The local and remote transmission power in dB.
SNR Margin The local and remote Signal to Noise Ration (SNR) margin in dB.
The SNR margin is the difference between the amount of noise received by the
by the local/remote line end, and the amount of noise it can tolerate.
Line
Attenuation
The local and remote line attenuation in dB.
The line attenuation is the difference between the signal power transmitted to
the local/remote line end, and that which it received.
