Cisco 2100 Series Configuration Guide

4-60
Cisco Wireless LAN Controller Configuration Guide
OL-17037-01
Chapter 4 Configuring Controller SettingsWireless Device Access
Configuring Voice and Video Parameters
This page shows the TSM statistics for this client and the access point to which it is associated. The
statistics are shown in 90-second intervals. The timestamp field shows the specific interval when the
statistics were collected.
Step 5 Follow these steps to see the TSM statistics for a particular access point and a particular client associated
to this access point.
a. Click Wireless > Access Points > Radios > 802.11a/n or 802.11b/g/n. The 802.11a/n Radios or
802.11b/g/n Radios page appears (see Figure 4-23).
Figure 4-23 802.11a/n Radios Page
b. Hover your cursor over the blue drop-down arrow for the desired access point and choose
802.11aTSM or 802.11b/gTSM. The AP > Clients page appears (see Figure 4-24).

Cisco 2100 Series Specifications

General

Power over Ethernet (PoE)	No
Form Factor	Desktop
Encryption	AES, TKIP
Maximum Access Points	6
Security	WPA, WPA2, 802.1X
Dimensions	1.75 x 8.0 x 8.5 in. (4.4 x 20.3 x 21.6 cm)
