Cisco 7000 Hardware Installation And Maintenance

Preparing for Installation 2-113
Site Log
Router mounted in rack (optional)
First power supply installed in lower bay
Second (optional) power supply installed in upper bay
AC power cord connected to AC source and router; retention clip secured
DC power cable connected to DC source and router; strain relief secured
All ejector levers checked and secure
Captive installation screws on RP, SP (or SSP), RSP7000, RSP7000CI, interface processors, and power
supplies checked
Port Configuration Worksheet completed (optional)
Network interface cables and devices connected
Flash memory card (if present) inserted all the way into PCMCIA slot
ASCII terminal attached to console port
Console port set for 9600 baud, 8 data bits, 2 stop bits, no parity
All power supplies turned on (power LED lights on each supply)
Upper/lower power LEDs light for all power supplies
System boot complete (Normal LEDs light)
RP and SP (or SSP), or RSP7000, and all interface processors operational (enabled LED indicator on SP
[or SSP] and all interface processors is on)
Console screen displays correct hardware configuration (displayed after system banner)
System ready for global and interface-specific configuration
1. Refer to the related software documentation for first-time software configuration requirements.
Component Description Rec’d
Chassis Router chassis
Accessories The following accessories may arrive in separate shipping containers:
Rack-mount kit Two brackets, two chassis ears (each holds two captive grommets), and fasteners (screws).
Cable management kit Two brackets and Phillips screws for attaching the brackets to the chassis
Power cable One power cable
EIP port jackscrews One jackscrew conversion kit for each Ethernet port
FEIP port jackscrews One jackscrew conversion kit for each Fast Ethernet port
FSIP interface cables Verify that you receive 1 of the following adapter cables for each FSIP port:
EIA/TIA-232 DTE or DCE serial port adapter cable, 1 per port required
EIA/TIA-449 DTE or DCE serial port adapter cable, 1 per port required
V.35 DTE or DCE serial port adapter cable, 1 per port required
X.21 DTE or DCE serial port adapter cable, 1 per port required
EIA-530 DTE serial port adapter cable, 1 per port required
One pair of M-30 metric thumbscrews with each cable type except V.35
Optional interface cables AUI or Ethernet transceiver cable, 1 per EIP port required
One jackscrew conversion kit for each Ethernet AUI ports (install only if needed)
Token Ring interface cable, 1 per TRIP port required
Task Verified by Date

Cisco 7000 Specifications

General

Product Type	Switch
Model	7000
Category	Switch
Ports	Varies by configuration
Power Supply	Redundant power supplies supported
Management	SNMP, CLI
