Cisco Catalyst 4500 Series Configuration Guide

15-30
Software Configuration Guide—Release IOS XE 3.3.0SG and IOS 15.1(1)SG
OL-25340-01
Chapter 15 Configuring VLANs, VTP, and VMPS
VLAN Membership Policy Server
Figure 15-4 Dynamic Port VLAN Membership Configuration
Two topologies are possible. Figure 15-5 illustrates a topology with one end station attached directly to
a Catalyst 4500 series switch operating as a VMPS client. Figure 15-6 illustrates a topology with an end
station attached to a Cisco IP Phone, which is attached to a Catalyst 4500 series switch.
Figure 15-5 Topology with an End Station Attached Directly to a Catalyst 4500 Series Switch
Operating as a VMPS Client
Primary VMPS
Server 1
Secondary VMPS
Server 2
Secondary VMPS
Server 3
172.20.26.150
172.20.26.151
Catalyst 4000
(CatOS)
Catalyst 6000
(CatOS)
URT
172.20.26.152
Ethernet segment
172.20.26.153
172.20.26.154
172.20.26.155
172.20.26.156
172.20.26.157
172.20.26.158
172.20.26.159
Client
Client
End
station 2
End
station 1
TFTP server
3/1
Switch 10
Switch 9
Switch 8
Switch 7
Switch 6
Switch 5
Switch 3
Switch 2
Switch 1
Switch 4
172.20.22.7
130105
Router
Endstation
(in VLAN 10)
Catalyst 4500 (IOS)
(VMPS client)
Catalyst 4500 (CatOS)/
Catalyst 6500 (CatOS)/
URT
(VMPS server)
130118
Internet
