5 Use the RIGHT arrow key to move to the right and select PID to display the
detailed menu level.
6 Configure the input to output channel mapping. Video and PCR (Program Clock
Reference) can be output on the same PID or different PIDs. If output on the
same PID, they will appear identical to the input.
Note: If the parameters cannot be saved, the problem may be that the incorrect
Map Mode has been selected. Ensure that Svc ID & PID is selected when
remapping PIDs, otherwise a message such as “Bad configuration data” will be
displayed and you will need to change the parameters to obtain the correct
output.
7 Go to Setup: Outputs, TS Out: ASI, and set the Output Mode to Full DPM
Control. Also, if necessary set the Descramble Mode according to whether the
program is to be Scrambled or Descrambled for downstream
viewing/monitoring.
8 On the same menu, set the following parameters:
9 Set the table parameters as follows:
