Cisco D9824 User Manual

Chapter 6 Service and Maintenance
338
Warning
Message
Type
Message
Cause/Remedy
Description
ID
SDI VBI (OP47
SDP)
Clear
Service disabled
–
–
90050
SDI VBI (OP47
MDP)
Set
VBI (OP47MDP):
configured line
collides with VII,
service will be
dropped
Cause: User selection.
Remedy: Change offset
for VBI OP47-MDP
VANC service.
VBI OP47-MDP
VANC service is
configured on the line
overlapping with PAL
or NTSC VII line.
90060
SDI VBI (OP47
MDP)
Clear
Line collision
with VII cleared
–
–
90060
SDI VBI (OP47
MDP)
Clear
Service disabled
–
–
90060
ETH REDN:
Link Speed
Set
Links speed
mismatch
detected
Cause: Manual
configuration or auto-
negotiated speed is
different.
Remedy: Make sure link
speed on paired ETH
ports are identical.
Link speed is different
for two paired Eth
ports. In case of
REDN-controlled
switch this might
trigger overflow on
port with lower link
speed. The condition
for this fault is only
monitored for "auto"
REDN modes.
91000
ETH REDN:
Link Speed
Clear
Link speeds are
identical (or not
resolved)
–
–
91000
ETH REDN:
Link Speed
Clear
Link speed is not
resolved
–
–
91000
ETH REDN:
Link Speed
Clear
Links speed is
not monitored in
manual modes
–
–
91000
MPoIP Bitrate
Port #<n>
Set
Total configured
output is
marginal or too
high
Cause: Aggregated
MPoIP bandwidth on
Port <n> is too high.
Remedy: Re-configure
the stream's output rate
to be within 90% of the
link speed on ETH port
<n>.
The configured MPEG
over IP bandwidth is
close or higher than
ETH port <n> link
speed. This condition
can trigger the actual
MPoIP overflow.
92000
92100
MPoIP Bitrate
Port #<n>
Clear
Total configured
output is normal
–
–
92000
92100
