Cisco D9824 User Manual

337
Warning
Message
Type
Message
Cause/Remedy
Description
ID
SDI CC VANC
Set
CC (SMPTE-
334): configured
line collides with
VII, service will
be dropped
Cause: User selection.
Remedy: Change offset
for the CC VANC
service.
CC VANC service is
configured on the line
overlapping with PAL
or NTSC VII line.
90010
SDI CC VANC
Clear
Line collision
with VII cleared
–
–
90010
SDI CC VANC
Clear
Service disabled
–
–
90010
SDI AFD VANC
Set
AFD (SMPTE-
2016-3):
configured line
collides with VII,
service will be
dropped
Cause: User selection.
Remedy: Change offset
for the AFD VANC
service.
AFD VANC service is
configured on the line
overlapping with PAL
or NTSC VII line.
90020
SDI AFD VANC
Clear
Line collision
with VII cleared
–
–
90020
SDI AFD VANC
Clear
Service disabled
–
–
90020
SDI DPI VANC
Set
DPI (RP2010):
configured line
collides with VII,
service will be
dropped
Cause: User selection.
Remedy: Change offset
for the DPI VANC
service.
DPI VANC service is
configured on the line
overlapping with PAL
or NTSC VII line.
90030
SDI DPI VANC
Clear
Line collision
with VII cleared
–
–
90030
SDI DPI VANC
Clear
Service disabled
–
–
90030
SDI VBI VANC
Set
VBI (SMPTE-
2031): configured
line collides with
VII, service will
be dropped
Cause: User selection.
Remedy: Change offset
for the VBI VANC
service.
VBI VANC service is
configured on the line
overlapping with PAL
or NTSC VII line.
90040
SDI VBI VANC
Clear
Line collision
with VII cleared
–
–
90040
SDI VBI VANC
Clear
Service disabled
–
–
90040
SDI VBI (OP47
SDP)
Set
VBI (OP47SDP):
configured line
collides with VII,
service will be
dropped
Cause: User selection.
Remedy: Change offset
for VBI OP47-SDP
VANC service.
VBI OP47-SDP VANC
service is configured
on the line
overlapping with PAL
or NTSC VII line.
90050
SDI VBI (OP47
SDP)
Clear
Line collision
with VII cleared
–
–
90050
