Chapter 4 Front Panel Operation
58
Global Status
Menu Item
Description
Parameters
State

Displays the current disaster recovery status.
For more information on the statuses, see
Viewing the Disaster Recovery Status (on page
174).
No Disaster - D/R
Ready, D/R in
progress, D/R disabled
- Maintenance Mode,
D/R disabled, No
Disaster - D/R Ready
(Transport Only), No
Disaster - D/R Not
Ready (No Search
Path), No Disaster -
D/R Not Ready
(Malformed DRT), D/R
in progress (Transport
Only), D/R in progress
(No search path), D/R
in progress - D/R Not
Ready (Malformed
DRT), NIT Retune
Recovery in progress,
Goto RF n -
OK/FAIL/No Action,
Goto Backup n -
OK/FAIL/No Action,
Goto Origin -
OK/FAIL/No Action,
Goto Preferred RF -
OK/FAIL/No Action
Configured By
Displays the current disaster recovery setting.

User - The unit is using the disaster recovery
settings configured locally.

Uplink - The unit is using the PNC disaster
recovery profile.
User or Uplink
Signal Loss Timer
Indicates the time, in seconds, the unit must wait
(after detecting a signal loss) before declaring a
disaster.
If the Profile is set to User, it displays the time set
by the local unit.
If the Profile is set to Uplink, it displays the time
set by the PNC uplink. But if the unit is not
connected to the uplink, the default value of the
unit is displayed.
5 to 2160000
