Cisco D9824 User Manual

Status Menu
59
Menu Item
Description
Parameters
Signal Lock Timer
Indicates the time, in seconds, the unit must wait
for a signal lock before declaring that the signal is
not usable and move on to the next search location
in the search path.
If the Profile is set to User, it displays the time set
by the local unit.
If the Profile is set to Uplink, it displays the time
set by the PNC uplink. But if the unit is not
connected to the uplink, the default value of the
unit is displayed.
5 to 255
Verify Timer
Indicates the time, in seconds, the unit must wait
for the PAT table to verify the signal has a valid
transport.
If the Profile is set to User, it displays the time set
by the local unit.
If the Profile is set to Uplink, it displays the time
set by the PNC uplink. But if the unit is not
connected to the uplink, the default value of the
unit is displayed.
10 to 255
Backup Channel Status
Menu Item
Description
Parameters
PE
Displays the program entry.
PE1 to PE32
Backup Channel
Displays the channel number assigned to the
selected backup transport.
–
Transport #
Displays the backup transport number for the
program entry selected.
1, 2, or 3
Backup Transport Status
Menu Item
Description
Parameters
Backup
Indicates the configured backup transport entry
number.
1, 2, or 3
Input, NetId, Freq
(GHz), SymRate,
FEC, OrbPos, E/W,
Pol, Modulation,
Rolloff, Config by
For information on the tuning parameters, see
Status Menu: TS Input (on page 50).
Note: The RF input must be configured to match
the bandwidth of the backup parameters.
–
