Chapter 4 Front Panel Operation
This is the symbol rate. The symbol rate must
match that of the transmitted signal.
1.0 to 45.0 Ms/s for DVB-
S.
1.0 to 30.0 Ms/s for DVB-
S2 if Pilot Present is set to
Yes.
5.0 to 30.0 Ms/s for DVB-
S2 if Pilot Present is set to
No.
Select the Forward Error Correction (FEC)
inner code rate. The FEC must match the FEC
of the transmitted signal.
1/2, 2/3, 3/4, 5/6, 7/8, or
Auto
This is the L-Band operating frequency used by
the receiver. This value is determined by the
values set in the Freq and LO options.
Indicate whether the tuner has locked onto the
Radio Frequency signal with the current
settings.
Sets the modulation type for the received
signal.
Sets the rolloff factor of the incoming signal.
.20, .25, .35. Use .20 or .35
when DVB-S modulation
is used, and either of the
three when DVB-S2 is
used. Use a small number
to reject or filter carriers
close to the same
frequency.
Select the Input signal spectrum inversion
setting, which allows the operator to track and
select inverted and non-inverted digital
signals. This is normally used to automatically
reject or filter out unwanted signals.
Auto, Normal, or
Opposite.
Auto - The signal is
tracked and inverted for
correct selection, as
required.
Opposite - The signal is
always inverted.
Normal - The signal is not
inverted.
Select the Network ID of the uplink signal the
receiver is to receive. The receiver's Network
ID must match the Network ID associated with
the transmitted signal.
1 to 65535. The default
value is 1.
