Cisco D9858 User Manual

Chapter 4 Front Panel Operation
82
Menu Item
Description
Parameters
Stereo/Mono
Sets the output mixing.
Stereo - Left and Right are passed
directly through to Left and Right
R-MONO - Right is passed to both the
Left and Right
L-MONO - Left is passed to both the
Left and Right
Mixed - Left is passed to both the Left
and Right, and Right is passed to both
the Left and Right.
AC3 Compression
Sets the AC3 compression mode to
use if the output is compressed
Dolby Digital audio.
Line Mode, Custom 1, Custom 0 or
RF Mode.
RF Mode is recommended for analog
cable modulators.
Left (dB)
Sets the volume adjustment for the
Left audio channel, in dB.
-6.0 to +6.0
Any value can be entered with the
numeric keypad (in the appropriate
range), but the UP and DOWN
arrows will increase or decrease in 0.5
dB steps.
Right (dB)
Sets the volume adjustment for the
Right audio channel, in dB.
-6.0 to +6.0
Any value can be entered with the
numeric keypad (in the appropriate
range), but the UP and DOWN
arrows will increase or decrease in 0.5
dB steps.
Select Language By
Method of selecting the audio PID
for the local audio decoding. This is
required if the monitored program
contains more than two audio PIDs.
PMT Order, Language List, Language
Entry
PMT Order (default) - Allows you to
select a PMT order.
Language List - Allows you to select a
language from the available list.
Language Entry - Allows you to enter
a language code.
