Setup Menu
89
Cueing
Menu Item
Description
Parameters
Cueing Mode
Select whether cueing output
should be DTMF tones or
trigger pins.
Tone - Cue tones are standard Dual-
Tone Multi-Frequency (DTMF) tones.
The tones are generated at the Cue
Tone/Relay output on the rear panel
of the receiver.
Trigger - Cue trigger refers to open-
collector pins which can be toggled at
the Cue Tone/Relay output on the
rear panel of the receiver.
Trigger Polarity
If the Cueing Mode was set to
Trigger, select the pin polarity.
High - Pins act as open or floating
collectors on an active cueing signal
and as ground on an inactive signal.
Low - Pins act as ground on an active
cueing signal and as open or floating
collectors on an inactive signal.
Repeat
If the Cueing Mode was set to
Tone, set the number of
consecutive tone sequences to
be generated. Values greater
than 1 are provided when a
scenario demands repetition to
ensure that the ad insertion
equipment receives the signal.
1, 2, or 3. The default is 3.
Tone (ms)
If the Cueing Mode was set to
Tone, set the duration of each
tone, in milliseconds.
0 to 80. The default is 40.
Silence (ms)
If the Cueing Mode was set to
Tone, set the duration, in
milliseconds, of each silence
between tones.
0 to 80. The default is 40.
Seq#
Select the tone sequence to
configure.
1 to 16
State
Select whether the current tone
sequence is enabled or disabled.
Enabled or Disabled. When disabled,
no cue tone is output.
Tones
Sets the three digit tone
sequence.
000 to 999
