Cisco D9858 User Manual

Chapter 4 Front Panel Operation
90
Menu Item
Description
Parameters
Mode
Sets the tone sequence mode.
* - Start tone only
# - End tone only
*/# - Start and end tones. The end
tone is signaled after waiting the time
specified in Delay(sec).
Delay(sec)
If the Mode was set to */#
(Start/Stop), set the delay, in
seconds, between the start and
stop sequences.
1 to 255. The default is 30.
Relay Mode
The relay can be programmed
to respond to an alarm or
warning state, or the state of
one of the eight cue trigger
pins. The response is generated
at the Cue Tone/Relay output
on the rear panel of the
receiver.
Alarm or Trigger
The following table displays the
possible field settings and their
relationship to the receiver output:
Relay
Mode
Condition
Relay
Contact
NC-
C
C-No
Alarm
Unit Power
Off
Open
Close
Alarm State
Open
Close
No Alarm
Close
Open
Trigger
Active
(selected in
PNC)
Close
Open
Inactive
Open
Close
Cue Trigger Bit
If the Relay Mode was set to
Trigger, select the cue trigger
bit/pin that will activate the
relay.
1 to 8
Cue Tone Test
Sets the three digit cueing tone
test sequence.
000 to 999
Mode
Sets the test sequence mode.
* - Start tone
# - End tone
Run Test
Select and press continue to run
the cue tone test according to
the Cue Tone Test and Mode.
