Setup Menu
91
TS Out - ASI
Menu Item
Description
Parameters
Name
Displays the name
assigned to the transport
output for ease of
reference. This is read-
only.
20-character string
Rate Control
Select the output rate
control.
Auto - The output rate follows that set by the
uplink. This setting can be used if the signal
source is ASI. If Insert Null Packet is set to Yes,
the output bit rate is the same as the input rate
(including all the null packets). If Insert Null
Packet is set to No, the output rate is equal to the
payload rate of the transport stream to be
encapsulated, and in most cases, it will be lower
than the overall input rate.
User - The output rate is specified by the User
Rate(Mbps) parameter. It is determined by the
user setting regardless of the input source. Null
packets are always inserted when the configured
output bit rate is higher than the payload rate of
the transport stream to be encapsulated.
User
Rate(Mbps)
If the Rate Control is set to
User, set the maximum
output bit rate. If null
packets are inserted, this
will be the output rate.
This setting is used when
the signal source is RF or
ASI and allows you to set
the output bit rate to a
value expected by
equipment connected to
the ASI output.
0 to 206 Mbps
Note: Output data may be lost if this bit rate is set
to a value less than the actual signal bit rate.
