Cisco D9858 User Manual

Setup Menu
105
Menu Item
Description
Parameters
Act
Select the action to perform on
the current PID.
The Drop action is always
performed, but the Map option
is only applied if the PE action
is Map and the Map Mode is
Svc ID & PID.
Map - The service selected by the
OutType and Instance will be
mapped to the specified PID. This is
only applied if the PE action is Map
and the Map Mode is Svc ID & PID.
Drop - The service selected by the
OutType and Instance will be
removed from the PMT and the
output stream.
StTyp
Enter the stream type to map
within a PE to a specified PID.
0 to 255
OTyp
Select the service to configure.
If an input service matches this
type and instance specified by
In, then the Action will be
applied.
UNKN, ETV, CDT, LSDT, DATA,
TTX, MPE, DPI, VBI, SUBT, AUD,
VID, PCR or INVL
In
Select the instance of the service
specified by OutType to
configure. If an input service
matches this type and instance,
then the Action will be applied.
1 to 64
PID
If mapping this PID (Act is set
to Map), select the output PID
number.
1 to 8190
PSI Table Settings
Note: The table settings are only available if you selected Ctl by Table in the PSI
Options menu. The default values for the PSI table settings are dependent on the
Output Mode. For a list of default values, see DPM Default Settings for Different
Output Modes (on page 361).
Setting
Mode Options
Description
Default
PAT
Pass, Drop, Regen
Program Association
Table
Pass
CAT
Pass, Drop, Regen
Conditional Access Table
Pass
PMT
Pass, Drop, Regen
Program Map Table
Pass
TSDT
Pass, Drop
Transport Stream
Description Table
Pass
NIT
Pass, Drop, Regen, PwRC
Network Information
Table
Pass
