Setup Menu
125
Menu Item
Description
Parameters
D/R Profile
Select the disaster recovery setting to use.
Choose Local to use the disaster recovery
settings configured on the receiver, if the
PNC uplink is configured to allow local
disaster recovery.
Choose Uplink to use the PNC disaster
recovery profile. The PNC disaster
recovery profile is configured by the PNC
uplink administrator. For more
information, contact your PNC uplink
administrator.
Note: The PNC uplink determines whether
the local disaster recovery is used,
regardless of the D/R Profile setting. For
more information, see Disaster Recovery
(on page 7).
Local or Uplink
Signal Loss Timer
Select the time, in seconds, the unit must
wait (after detecting a signal loss) before
declaring a disaster. The default is 120
seconds.
5 to 2160000 seconds
Signal Lock Timer
Select the time, in seconds, the unit must
wait for a signal lock before declaring that
the signal is not usable and move on to the
next search location in the search path. The
default is 30 seconds.
5 to 255 seconds
Verify Timer
Select the time, in seconds, the unit must
wait for the PAT table to verify the signal
has a valid transport. The default is 60
seconds.
10 to 255 seconds
Backup Channel
Menu Item
Description
Parameters
PE #
The Program Entry (PE) number you are
configuring the backup transport channel.
The single channel transcoder (D9858-1)
supports one program entry (PE1) only.
The dual channel transcoder supports two
program entries (PE1 and PE2).
PE1 or PE2
Transport
The backup transport number you are
configuring the backup channel.
1, 2, or 3
