Cisco D9858 User Manual

Setup Menu
71
Menu Item
Description
Parameters
Gateway
Sets the Network Gateway Address
on the Network, used to expose the
receiver to a WAN.
The IP Address/Mask and Gateway
Address should be changed together,
as a group. The following table shows
the most commonly used Subnet mask
values to enter for a chosen IP address
mask, which will depend on the size of
your network.
Mask
Subnet Mask
8
255.0.0.0
16
255.255.0.0
24
255.255.255.0
Phy Mode
Set the speed and duplex type of the
interface. Select Auto for PHY to
negotiate speed and duplex with
other devices on the network, or
select 10 HD (half-duplex), 10 FD
(full-duplex), 100 HD, 100 FD, or 1000
FD to lock into a fixed mode.
Auto (default), 1000FD (full duplex),
100HD (half duplex), 10FD, 100FD, or
10HD
MAC Address
Displays the MAC address of the
interface. It is set at the factory and is
a read-only value.
N/A
SNMP Read Only
Community String
Sets the password to read data from a
device and to display diagnostics
traps/alarms.
This is used when communicating
with a device within an SNMP
environment.
Up to 31 alphanumeric characters in
length. This string is case-sensitive.
The default community string is:
public.
SNMP Read Write
Community String
Sets the password to write data to a
device.
This is used when communicating
with a device within an SNMP
environment.
Up to 31 alphanumeric characters in
length. This string is case-sensitive.
The default community string is:
public.
