Configuring Smartports Macros
Configuration Examples for Smartports Macros
Configuration Examples for Smartports Macros
Applying the Smartports Macro: Examples
This example shows how to display the cisco-ie-desktop macro, how to apply the macro and to set the access VLAN
ID to 25 on an interface:
Switch# show parser macro name cisco-ie-desktop
--------------------------------------------------------------
Macro name : cisco-ie-desktop
Macro type : default interface
# macro keywords ACCESS_VLAN
#macro name cisco-ie-desktop
switchport mode access
switchport access vlan ACCESS_VLAN
switchport port-security
switchport port-security maximum 1
switchport port-security aging time 2
switchport port-security violation restrict
switchport port-security aging type inactivity
spanning-tree portfast
spanning-tree bpduguard enable
no macro description
macro description cisco-ie-desktop
--------------------------------------------------------------
Switch#
Switch# configure terminal
Switch(config)# interface GigabitEthernet1/20
Switch(config-if)# macro apply cisco-ie-desktop $AVID 25
Additional References
The following sections provide references related to switch administration:
show parser macro name macro-name Displays a specific Smartports macro.
show parser macro brief Displays the Smartports macro names.
show parser macro description [interface
interface-id]
Displays the Smartports macro description for all interfaces or for a
specified interface.
Table 32 Commands for Displaying Smartports Macros (continued)
Command Purpose

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
