Cisco IE 4000 Software Configuration Guide

536
Configuring SNMP
How to Configure SNMP
Command Purpose
1. configure terminal Enters global configuration mode.
2. snmp-server engineID {local engineid-string
| remote ip-address [udp-port port-number]
engineid-string}
Configures a name for either the local or remote copy of SNMP.
 The engineid-string is a 24-character ID string with the name
of the copy of SNMP. You need not specify the entire
24-character engine ID if it has trailing zeros. Specify only the
portion of the engine ID up to the point where only zeros
remain in the value. For example, to configure an engine ID of
123400000000000000000000, you can enter this:
snmp-server engineID local 1234
 If you select remote, specify the ip-address of the device that
contains the remote copy of SNMP and the optional User
Datagram Protocol (UDP) port on the remote device. The
default is 162.

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
