Cisco IE 4000 Software Configuration Guide

55
Configuring Switch Alarms
Configuration Examples for Switch Alarms
Configuration Examples for Switch Alarms
Configuring External Alarms: Example
This example configures alarm input 1 named door sensor to assert a major alarm when the door circuit is closed and
then displays the status and configuration for all alarms:
Switch(config)# alarm contact 1 description door sensor
Switch(config)# alarm contact 1 severity major
Switch(config)# alarm contact 1 trigger closed
Switch(config)# end
Switch(config)# show env alarm-contact
Switch# show env alarm-contact
ALARM CONTACT 1
Status: not asserted
Description: door sensor
Severity: major
Trigger: closed
ALARM CONTACT 2
Status: not asserted
Description: external alarm contact 2
Severity: minor
Trigger: closed
Associating Temperature Alarms to a Relay: Examples
This example sets the secondary temperature alarm to the major relay, with a high temperature threshold value of 113
o
F
(45
o
C). All alarms and traps associated with this alarm are sent to a syslog server and an SNMP server.
Switch(config) # alarm facility temperature secondary high 45
Switch(config) # alarm facility temperature secondary relay major
Switch(config) # alarm facility temperature secondary syslog
Switch(config) # alarm facility temperature secondary notifies
This example sets the first (primary) temperature alarm to the major relay. All alarms and traps associated with this alarm
are sent to a syslog server.
Switch(config) # alarm facility temperature primary syslog
Switch(config) # alarm facility temperature primary relay major
Configuring a Dual Power Supply: Examples
This example shows how to configure two power supplies:
Switch# configure terminal
show alarm settings Displays all global alarm settings on the switch.
show env {alarm-contact | all | power |
temperature}
Displays the status of environmental facilities on the switch.
show facility-alarm status [critical | info |
major | minor]
Displays generated alarms on the switch.
Table 13 Commands for Displaying Global and Port Alarm Status (continued)
Command Purpose

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
