Cisco IE 4000 Software Configuration Guide

56
Configuring Switch Alarms
Configuration Examples for Switch Alarms
Switch(config)# power-supply dual
These examples show how to display information when two power supplies are not present which results in a triggered
alarm.
Switch# show facility-alarm status
Source Severity Description Relay Time
Switch MAJOR 5 Redundant Pwr missing or failed NONE Mar 01
1993 00:23:52
Switch# show env power
POWER SUPPLY A is DC OK
POWER SUPPLY B is DC FAULTY <--
Switch# show hard led
SWITCH: 1
SYSTEM: GREEN
ALARM : ALT_RED_BLACK <--
Displaying Alarm Settings: Example
Switch# show alarm settings
Alarm relay mode: De-energized
Power Supply
Alarm Enabled
Relay
Notifies Disabled
Syslog Enabled
Temperature-Primary
Alarm Enabled
Thresholds MAX: 95C MIN: -20C
Relay MAJ
Notifies Enabled
Syslog Enabled
Temperature-Secondary
Alarm Disabled
Threshold
Relay
Notifies Disabled
Syslog Disabled
License-File-Corrupt
Alarm Enabled
Relay
Notifies Enabled
Syslog Enabled
Switch# show alarm settings
Alarm relay mode: De-energized
Power Supply
Alarm Enabled
Relay
Notifies Disabled
Syslog Enabled
Temperature-Primary
Alarm Enabled
Thresholds MAX: 95C MIN: -20C
Relay MAJ
Notifies Enabled
Syslog Enabled
Temperature-Secondary
Alarm Disabled
Threshold
Relay

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
