965
Configuring Cisco IOS IP SLAs Operations
How to Configure Cisco IOS IP SLAs Operations
Command Purpose
1. configure terminal Enters global configuration mode.
2. ip sla operation-number Creates an IP SLAs operation, and enters IP SLAs configuration mode.
3. udp-jitter {destination-ip-address
| destination-hostname}
destination-port [source-ip
{ip-address | hostname}]
[source-port port-number]
[control {enable | disable}]
[num-packets
number-of-packets] [interval
interpacket-interval]
Configures the IP SLAs operation as a UDP jitter operation, and enters UDP
jitter configuration mode.
destination-ip-address | destination-hostname—Specifies the destination
IP address or hostname.
destination-port—Specifies the destination port number in the range from
1 to 65535.
(Optional) source-ip {ip-address | hostname}—Specifies the source IP
address or hostname. When a source IP address or hostname is not
specified, IP SLAs chooses the IP address nearest to the destination.
(Optional) source-port port-number—Specifies the source port number in
the range from 1 to 65535. When a port number is not specified, IP SLAs
chooses an available port.
(Optional) control—Enables or disables sending of IP SLAs control
messages to the IP SLAs responder. By default, IP SLAs control messages
are sent to the destination device to establish a connection with the IP
SLAs responder.
(Optional) num-packets number-of-packets—Enters the number of
packets to be generated. The range is 1 to 6000; the default is 10.
(Optional) interval inter-packet-interval—Enters the interval between
sending packets in milliseconds. The range is 1 to 6000; the default value
is 20 ms.
4. frequency seconds (Optional) Sets the rate at which a specified IP SLAs operation repeats. The
range is from 1 to 604800 seconds; the default is 60 seconds.
