Gain (dBi)ModelPart Number
14.04.9- to 5-GHz patch2AIR-ANT5114P-N
17.04.9- to 5-GHz 90-degree sector2AIR-ANT5117S-N
4 dBi at 2.4 GHz and 7 dBi at
5 GHz
2.4- to 5-GHz dual-band
omnidirectional
AIR-ANT2547V-N
6
The compact omnidirectional antennas mount directly on the access point.
7
The compact omnidirectional antennas mount directly on the access point.
8
Use of the 4.9-GHz band requires a license and may be used only by qualified Public Safety operators as defined in section 90.20 of the FCC rules.
See the Cisco Aironet Antenna and Accessories Reference Guide on Cisco antennas and accessories at http:/
/www.cisco.com/en/US/prod/collateral/wireless/ps7183/ps469/product_data_sheet09186a008008883b.html
The deployment and design, limitations and capabilities, and basic theories of antennas as well as installation
scenarios, regulatory information, and technical specifications are addressed in detail.
Table 8: Horizontal and Vertical Beamwidth for Cisco Antennas, on page 28 summarizes the horizontal and
vertical beamwidth for Cisco antennas.
Table 8: Horizontal and Vertical Beamwidth for Cisco Antennas
Vertical Beamwidth (degrees)Horizontal Beamwidth (degrees)Antenna
16360AIR-ANT5180V-N
6060AIR-ANT58G10SSA-N
2925AIR-ANT5114P-N
890AIR-ANT5117S-N
30360AIR-ANT2547V-N
N-Connectors
All external antennas are equipped with male N-connectors.
AP1552 E/H have three N-connectors to connect dual-band antennas.
AP1552 C/I have no N-connectors as they come with inbuilt antennas.
AP1522 has three separate N-connectors to attach two 2.4-GHz antennas and one N-connector for a 5- GHz
antenna.
AP1524PS and AP1524SB have five N connectors to attach three 2.4-GHz antennas and two N connectors
for 5-GHz/4.9-GHz bands.
Each radio has at least one TX/RX port. Each radio must have an antenna connected to at least one of its
available TX/RX ports.
Antenna locations for 5.8 GHz, 4.9 GHz, and 2.4 GHz are fixed and labeled.
Cisco Mesh Access Points, Design and Deployment Guide, Release 7.3
28 OL-27593-01
Mesh Network Components
Cisco Outdoor Mesh Access Points
