indicates that there is a path termination error upstream in the data. The error is read as a BDI bit in the path
monitoring area of the digital wrapper overhead.
Clear the ODUK-BDI-PM Condition
SUMMARY STEPS
1. Complete the Clear the OTUK-BDI Condition, on page 341 procedure.
DETAILED STEPS
Complete the Clear the OTUK-BDI Condition, on page 341 procedure.
If the condition does not clear, log into the Technical Support Website at http://www.cisco.com/c/en/us/support/index.html
for more information or call Cisco TAC (1 800 553-2447).
ODUK-LCK-PM
Default Severity: Not Reported (NR), Non-Service-Affecting (NSA)
Logical Object: TRUNK
The ODUK Locked Defect (LCK) PM condition applies to TXP_MR_10G, TXP_MR_2.5G, TXPP_MR_2.5G,
TXP_MR_10E, TXP_MR_10E_C, TXP_MR_10E_L, MXP_2.5G_10G, AR_MXP, AR_XP, AR_XPE,
ADM-10G, and OTU2_XP cards when ITU-T G.709 encapsulation is enabled for the cards. ODUK-LCK-PM
indicates that a signal is being sent downstream to indicate that the upstream connection is locked, preventing
the signal from being passed. The lock is indicated by the STAT bit in the path overhead monitoring fields
of the optical transport unit overhead of the digital wrapper.
Clear the ODUK-LCK-PM Condition
SUMMARY STEPS
1. Unlock the upstream node signal.
DETAILED STEPS
Unlock the upstream node signal.
If the condition does not clear, log into the Technical Support Website at http://www.cisco.com/c/en/us/support/index.html
for more information or call Cisco TAC (1 800 553-2447).
Cisco NCS 2000 series Troubleshooting Guide, Release 11.0
318
Alarm Troubleshooting
Clear the ODUK-BDI-PM Condition
