SUMMARY STEPS
1. In node view (single-shelf mode) or multishelf view (multishelf mode), click the Provisioning > Defaults
tabs.
2. In the Defaults Selector field, click the card you wish to provision, then click Opticalthresholds > Trunk
> Warning > 15min in the drop-down list.
DETAILED STEPS
Step 1 In node view (single-shelf mode) or multishelf view (multishelf mode), click the Provisioning > Defaults tabs.
Step 2 In the Defaults Selector field, click the card you wish to provision, then click Opticalthresholds > Trunk > Warning
> 15min in the drop-down list.
Provision Individual Card BBE or SES Thresholds in CTC
Complete the following procedure to provision BBE or SES PM thresholds in CTC for an individual TXP
card.
SUMMARY STEPS
1. In node view (single-shelf mode) or shelf view (multishelf mode), double-click the applicable card (TXP,
MXP, or XP.)
2. Click the Provisioning > OTN > G.709 Thresholds tabs.
3. In the Directions area, click the Near End radio button.
4. In the Intervals area, click the 15 Min radio button.
5. In the Types area, click the PM (ODUk) radio button.
6. In the SES and BBE fields, enter threshold numbers, for example 500 and 10000.
DETAILED STEPS
Step 1 In node view (single-shelf mode) or shelf view (multishelf mode), double-click the applicable card (TXP, MXP, or XP.)
Step 2 Click the Provisioning > OTN > G.709 Thresholds tabs.
Step 3 In the Directions area, click the Near End radio button.
Step 4 In the Intervals area, click the 15 Min radio button.
Step 5 In the Types area, click the PM (ODUk) radio button.
Step 6 In the SES and BBE fields, enter threshold numbers, for example 500 and 10000.
Provision Card PM Thresholds Using TL1
Complete the following procedure if you wish to provision PM thresholds in TL1 rather than in CTC.
SUMMARY STEPS
1. Open a TL1 command line (click Tools > Open TL1 Connection).
Cisco NCS 2000 series Troubleshooting Guide, Release 11.0
30
General Troubleshooting
Provision Individual Card BBE or SES Thresholds in CTC
