DirectionLMP FailureTrunk Port Alarm
TxSDODUK-SD-PM
TxSDODUK-SD-TCM1
TxSDODUK-SD-TCM2
Table 13: Transponder Client Alarm that Causes LMP-SD
DirectionLMP FailureClient Port Alarm
RxSDSD
If the condition does not clear, log into the Technical Support Website at http://www.cisco.com/c/en/us/support/index.html
for more information or call Cisco TAC (1 800 553-2447).
LMP-SF
Default Severity: Not Alarmed (NA), Non-Service-Affecting (NSA)
Logical Object: GE
The LMP Data Link Signal Fail condition notifies the near-end user of a far-end problem (and thus is NSA
for the near end). The near-end control card receives an LMP link summary or channel status message that
the data link service has failed. The signal fail threshold provisionable.
LMP-SF clears when the control card receives a link summary or channel status message reporting that the
data link is in the Signal Okay (OK) state.
LMP-SF is part of an alarm hierarchy that includes LMP-SD, on page 256, and LMP-UNALLOC, on page
259. The hierarchy is as follows: If LMP-UNALLOC is raised, LMP-SF and LMP-SD are suppressed. If
LMP-SF is raised, it suppresses LMP-SD. LMP-SF and LMP-UNALLOC both suppress near-end LOS-type
alarms for DWDM clients, but LMP-SD does not suppress LOS-type alarms.
This condition clears when the far-end trouble has been cleared.
Clear the LMP-SF Condition
SUMMARY STEPS
1. Look for and clear any of the following alarms in Table 14: Transponder Card Alarms that Cause LMP-SF,
on page 258, Table 15: Transponder Trunk Alarms that Cause LMP-SF, on page 258, or Table 16:
Transponder Client Alarms that Cause LMP-SF, on page 258 occurring on the far-end port.
Cisco NCS 2000 series Troubleshooting Guide, Release 11.0
257
Alarm Troubleshooting
LMP-SF
