HP-DEG clears when the BER level falls to one-tenth of the threshold level that triggered the alarm.
Clear the HP-DEG Condition
SUMMARY STEPS
1. Complete the Clear the SD (TRUNK) Condition, on page 385 procedure.
DETAILED STEPS
Complete the Clear the SD (TRUNK) Condition, on page 385 procedure.
If the condition does not clear, log into the Technical Support Website at http://www.cisco.com/c/en/us/support/index.html
for more information or call Cisco TAC (1 800 553-2447).
HP-ENCAP-MISMATCH
Default Severity: Critical (CR), Service-Affecting (SA)
Logical Object: VCTRM-HP
The High-Order Path Encapsulation C2 Byte Mismatch alarm applies to ML-Series Ethernet cards. It occurs
when the first three following conditions are met and one of the last two is false:
• The received C2 byte is not 0x00 (unequipped).
• The received C2 byte is not a PDI value.
• The received C2 does not match the expected C2.
• The expected C2 byte is not 0x01 (equipped unspecified).
• The received C2 byte is not 0x01 (equipped unspecified).
(This is in contrast to LP-PLM, which must meet all five criteria.) For an HP-ENCAP-MISMATCH to be
raised, there is a mismatch between the received and expected C2 byte, with either the expected byte or
received byte value being 0x01.
An example situation that would raise an HP-ENCAP-MISMATCH alarm is if a circuit created between two
ML-Series cards has GFP framing provisioned on one end and high-level data link control (HDLC) framing
with LEX encapsulation provisioned on the other. The GFP framing card transmits and expects a C2 byte of
0x1B, while the HDLC framing card transmits and expects a C2 byte of 0x01.
A mismatch between the transmit and receive cards on any of the following parameters can cause the alarm:
• Mode (HDLC, GFP-F)
• Encapsulation (LEX, HDLC, PPP)
• CRC size (16 or 32)
• Scrambling state (on or off)
