Typical Card LED State After Successful Reset
When a non-DWDM card successfully resets, the following LED states are present:
If you are looking at the physical NCS system, the ACT/SBY LED is illuminated.
If you are looking at node view (single-shelf mode) or shelf view (multishelf mode) of the NCS system,
the current standby card has an amber LED depiction with the initials SBY, and this has replaced the
white LDG depiction on the card in CTC.
If you are looking at node view (single-shelf mode) or shelf view (multishelf mode) of the NCS system,
the current active card has a green LED depiction with the initials ACT, and this has replaced the white
LDG depiction on the card in CTC.
Frequently Used Alarm Troubleshooting Procedures
This section gives common procedures that are frequently used when troubleshooting alarms. Most of these
procedures are summarized versions of fuller procedures existing elsewhere in the system documentation.
They are included in this chapter for the user convenience. For further information, please refer to the
Configuration guide as appropriate to your purpose
Node and Ring Identification, Change, Visibility, and Termination
The following procedures relate how to identify or change BLSR names and node IDs, and how to verify
visibility from other nodes.
Identify a BLSR Ring Name or Node ID Number
SUMMARY STEPS
1. Log into a node on the network.
2. In node view, choose Go to Network View from the View menu.
3. Click the Provisioning > BLSR tabs.
4. From the Ring Name column, record the ring name, or in the Nodes column, record the Node IDs in the
BLSR. The Node IDs are the numbers in parentheses next to the node name.
DETAILED STEPS
Step 1 Log into a node on the network.
Step 2 In node view, choose Go to Network View from the View menu.
Step 3 Click the Provisioning > BLSR tabs.
Step 4 From the Ring Name column, record the ring name, or in the Nodes column, record the Node IDs in the BLSR. The Node
IDs are the numbers in parentheses next to the node name.
Cisco NCS 2000 series Troubleshooting Guide, Release 11.0
441
Alarm Troubleshooting
Typical Card LED State After Successful Reset
