D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 103
Cisco TelePresence MX700 and MX800
API Reference Guide
xCommand Camera Ramp
Move the camera in a specified direction. The camera moves at specified speed until a stop
command is issued. In a daisy chain, you need to know the CameraId for the camera you want
to address. Be aware that pan and tilt can be operated simultaneously, but no other combina-
tions. In the latter case only the first operation specified is executed. For example, if you try to
run both zoom and pan at the same time, only zoom is executed.
NOTE: You must run a stop command to stop the camera, see the example below.
Requires user role: USER
USAGE:
xCommand Camera Ramp CameraId: CameraId [Pan: Pan] [PanSpeed: Pa nSpeed] [Tilt:
T ilt] [TiltSpeed: TiltSpeed] [Zoo m: Zoom] [ZoomSpeed: ZoomSpeed] [Focus: Focus]
where
CameraId: Integer (1..7)
Select the camera.
Pan: Left/Right/Stop
Move the camera to the Left or Right, followed by Stop.
PanSpeed: I nte ge r (1..15)
Set the pan speed.
Tilt: Down/Up/Stop
Move the camera Up or Down, followed by Stop.
TiltSpeed: Inte ge r (1..15)
Set the tilt speed.
Zoom: In/Out/Stop
Zoom the camera In or Out, followed by Stop.
ZoomSpeed: In teg er (1..15)
Set the zoom speed.
Focus: Far/Near/Stop
Focus the camera Far or Near, followed by Stop.
xCommand Camera TriggerAutofocus
Trigger the auto-focus functionality. The camera must support auto-focus functionality. If the
camera is daisy chained, the CameraId is given by its place in the chain.
Requires user role: USER
USAGE:
xCommand Camera TriggerAutofocus CameraId: CameraId
where
CameraId: Integer (1..7)
Select the camera to auto-focus.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xCommand

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
