Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 96
Cisco TelePresence MX700 and MX800
API Reference Guide
xCommand Call FarEndControl Camera Stop
Stop the far end camera after the xCommand FarEndControl Camera Move has been issued.
Requires user role: USER
USAGE:
xCommand Call FarEndControl Camera Stop [C allId: CallId]
where
CallId: Integer (0..65534)
The CallID is returned when the xCommand Dial command is run. During a call you can
run the xStatus Call command to see the CallId.
xCommand Call FarEndControl RoomPreset Activate
While in a call, this command is used to activate a preset on the far end codec. The preset
covers the far end codec’s camera positions and input video switcher settings.
The preset must be stored on the far end codec beforehand, either by using the xCommand
Preset Store command locally on the far end codec, or by using the xCommand FarEndControl
Preset Store command from a remote codec.
Note: The far end codec’s xConfiguration Conference FarEndControl Mode setting must be
switched On for the FarEndControl commands to work.
Requires user role: USER
USAGE:
xCommand Call FarEndControl RoomPreset Activate [Ca llId: CallId] PresetId:
PresetId
where
CallId: Integer (0..65534)
The CallId is required to identify the far end codec only when in a Multipoint call. The
CallId is returned when issuing the xCommand Dial command. During a call you can run
the xStatus Call command to see the CallId.
PresetId: In teg er (1..15)
The ID of the preset that is stored on the far end codec.
xCommand Call FarEndControl Source Select
Select which video input source to use as the main source on the far end system.
Requires user role: USER
USAGE:
xCommand Call FarEndControl Source Select [CallId: CallId] SourceId: SourceId
where
CallId: Integer (0..65534)
The CallID is returned when the xCommand Dial command is run. During a call you can
run the xStatus Call command to see the CallId.
SourceId: I nte ge r (0..15)
Select a video input source on the far end.
xCommand Call Hold
Put a call on hold.
Requires user role: USER
USAGE:
xCommand Call Hold [CallId: CallId] [Reason: Reason]
where
CallId: Integer (0..65534)
The CallID is returned when the xCommand Dial command is run. During a call you can
run the xStatus Call command to see the CallId.
Reason: Conference/Transfer/Other
Internal usage only.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xCommand

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
