D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 111
Cisco TelePresence MX700 and MX800
API Reference Guide
Phonebook commands
xCommand Phonebook Contact Add
Requires user role: USER
USAGE:
xCommand Phonebook Contact Add Na me: "Name" [FolderId: "FolderId"] [Im ageURL:
"ImageURL"] [Title: "Title"] [Nu m ber: "Number"] [Protocol: Protocol] [CallRate:
CallRate] [CallTy p e: CallType] [Device: Device] [Tag: Tag]
where
Name: String (0, 255)
The name of the contact.
FolderId: String (0, 255)
The unique identifier for the folder that you want to store the contact in. The identifier
will be returned by an xCommand Phonebook Search command. It was also returned
when the xCommand Phonebook Folder Add command was issued to make the folder.
ImageURL: String (0, 255)
Currently not in use.
Title: String (0, 255)
The title of the contact.
Number: String (0, 255)
The phone number or address of the contact.
Protocol: Auto/H320/H323/SIP
Select the Auto, SIP, H323 or H320 protocol.
CallRate: Integer (0..6000)
Set a call rate.
CallType: Audio/Video
Select a call type (audio or video).
Device: Mobile/Other/Telephone/Video
Select the device type.
Tag: Untagged/Favorite
Tag the contact as a Favorite, or untag an already tagged contact.
xCommand Phonebook Contact Delete
Delete an existing contact from the local phonebook.
Requires user role: USER
USAGE:
xCommand Phonebook Contact Delete ContactId: "ContactId"
where
ContactId: String (0, 255)
The unique identifier for the contact. The identifier will be returned by an xCommand
Phonebook Search command. It was also returned when the xCommand Phonebook
Contact Add command was issued to make the contact.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xCommand

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
