Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 49
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Conference DefaultCall Rate
Define the Default Call Rate to be used when placing calls from the system.
Requires user role: ADMIN
Default value: 1920
USAGE:
xConfiguration Conference DefaultCall Rate: Rate
where
Rate : Integer (64..6000)
Set the default call rate (kbps).
xConfiguration Conference DoNotDisturb DefaultTimeout
This setting determines the default duration of a Do Not Disturb session, i.e. the period when
incoming calls are rejected and registered as missed calls. The session can be terminated
earlier by using the user interface (Touch controller). The default value is 60 minutes.
Requires user role: ADMIN
Default value: 60
USAGE:
xConfiguration Conference DoNotDisturb DefaultTimeout: Default Timeout
where
Defa ultTi m eout : Integer (0..1440)
Set the number of minutes (between 0 and 1440, i.e. 24 hours) before the Do Not
Disturb session times out automatically.
xConfiguration Conference Encryption Mode
Define the conference encryption mode. A padlock with the text "Encryption On" or
"Encryption Off" displays on screen for a few seconds when the conference starts.
NOTE: If the Encryption Option Key is not installed on the video system, the encryption mode is
always Off.
Requires user role: ADMIN
Default value: BestEffort
USAGE:
xConfiguration Conference Encryption Mod e: Mode
where
Mode : Off/On/BestEffort
Off: The system will not use encryption.
On: The system will only allow calls that are encrypted.
BestEffort: The system will use encryption whenever possible.
> In Point to point calls: If the far end system supports encryption (AES-128), the call will
be encrypted. If not, the call will proceed without encryption.
> In MultiSite calls: In order to have encrypted MultiSite conferences, all sites must
support encryption. If not, the conference will be unencrypted.
xConfiguration Conference FarEndControl Mode
Lets you decide if the remote side (far end) should be allowed to select your video sources and
control your local camera (pan, tilt, zoom).
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Conference FarEndControl Mode: Mode
where
Mode : Off/On
Off: The far end is not allowed to select your video sources or to control your local
camera (pan, tilt, zoom).
On: Allows the far end to be able to select your video sources and control your local
camera (pan, tilt, zoom). You will still be able to control your camera and select your
video sources as normal.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
