Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 44
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Cameras Camera [1..7] Backlight DefaultMode
This configuration turns backlight compensation on or off. Backlight compensation is useful
when there is much light behind the persons in the room. Without compensation the persons
will easily appear very dark to the far end.
Requires user role: USER
Default value: Off
USAGE:
xConfiguration Cameras Camera n Backlight Default Mode: DefaultMode
where
Default Mode : Off/On
Off: Turn off the camera backlight compensation.
On: Turn on the camera backlight compensation.
xConfiguration Cameras Camera [1..7] Brightness Mode
Define the camera brightness mode.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras Camera n Brightness Mode: Mode
where
Mode : Auto/Manual
Auto: The camera brightness is automatically set by the system.
Manual: Enable manual control of the camera brightness. The brightness level is set
using the Cameras Camera [n] Brightness DefaultLevel setting.
xConfiguration Cameras Camera [1..7] Brightness DefaultLevel
Define the brightness level. Requires the Cameras Camera [n] Brightness Mode to be set to
Manual.
Requires user role: USER
Default value: 20
USAGE:
xConfiguration Cameras Camera n Brightness DefaultLevel: DefaultLevel
where
Defa ultLevel : Integer (1..31)
The brightness level.
xConfiguration Cameras Camera [n..7] Focus Mode
This setting applies to Camera [2..7] for single camera systems, and to HDMI [3..7] for dual
camera systems.
Define the camera focus mode.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras Camera n Focus Mode: Mode
where
Mode : Auto/Manual
Auto: The camera will auto focus once a call is connected, as well as after moving the
camera (pan, tilt, zoom). The system will use auto focus only for a few seconds to set
the right focus; then auto focus is turned off to prevent continuous focus adjustments of
the camera.
Manual: Turn the autofocus off and adjust the camera focus manually.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
