D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 57
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Network [1] IEEE8021X Eap Md5
Define the Md5 (Message-Digest Algorithm 5) mode. This is a Challenge Handshake
Authentication Protocol that relies on a shared secret. Md5 is a Weak security.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Network n IEEE8021X Eap Md5: Md5
where
n : Index that identifies the network. Range: 1..1
Md5 : Off/On
Off: The EAP-MD5 protocol is disabled.
On: The EAP-MD5 protocol is enabled (default).
xConfiguration Network [1] IEEE8021X Eap Ttls
Define the TTLS (Tunneled Transport Layer Security) mode. Authenticates LAN clients without
the need for client certificates. Developed by Funk Software and Certicom. Usually supported
by Agere Systems, Proxim and Avaya.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Network n IEEE8021X Eap Ttls: Ttls
where
n : Index that identifies the network. Range: 1..1
Ttls : Off/On
Off: The EAP-TTLS protocol is disabled.
On: The EAP-TTLS protocol is enabled (default).
xConfiguration Network [1] IEEE8021X Eap Tls
Enable or disable the use of EAP-TLS (Transport Layer Security) for IEEE802.1x connec-
tions. The EAP-TLS protocol, defined in RFC 5216, is considered one of the most secure EAP
standards. LAN clients are authenticated using client certificates.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Network n IEEE8021X Eap Tls: Tls
where
n : Index that identifies the network. Range: 1..1
Tls : Off/On
Off: The EAP-TLS protocol is disabled.
On: The EAP-TLS protocol is enabled (default).
xConfiguration Network [1] IEEE8021X Eap Peap
Define the Peap (Protected Extensible Authentication Protocol) mode. Authenticates LAN
clients without the need for client certificates. Developed by Microsoft, Cisco and RSA Security.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Network n IEEE8021X Eap Peap: Peap
where
n : Index that identifies the network. Range: 1..1
Peap : Off/On
Off: The EAP-PEAP protocol is disabled.
On: The EAP-PEAP protocol is enabled (default).
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
