D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 52
Cisco TelePresence MX700 and MX800
API Reference Guide
H323 configuration
xConfiguration H323 Authentication Mode
Define the authenticatin mode for the H.323 profile.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration H323 Authentication Mode: Mode
where
Mode : Off/On
Off: The system will not try to authenticate itself to a H.323 Gatekeeper, but will still try
a normal registration.
On: If an H.323 Gatekeeper indicates that it requires authentication, the system will try
to authenticate itself to the gatekeeper. Requires the H323 Authentication LoginName
and H323 Authentication Password settings to be defined on both the codec and the
Gatekeeper.
xConfiguration H323 Authentication LoginName
The system sends the H323 Authentication Login Name and the H323 Authentication Password
to an H.323 Gatekeeper for authentication. The authentication is a one way authentication from
the codec to the H.323 Gatekeeper, i.e. the system is authenticated to the gatekeeper. If the
H.323 Gatekeeper indicates that no authentication is required, the system will still try to register.
Requires the H.323 Authentication Mode to be enabled.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration H323 Authentication LoginNa me: "LoginName"
where
LoginName : String (0, 50)
The authentication login name.
xConfiguration H323 Authentication Password
The system sends the H323 Authentication Login Name and the H323 Authentication Password
to an H.323 Gatekeeper for authentication. The authentication is a one way authentication from
the codec to the H.323 Gatekeeper, i.e. the system is authenticated to the gatekeeper. If the
H.323 Gatekeeper indicates that no authentication is required, the system will still try to register.
Requires the H.323 Authentication Mode to be enabled.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration H323 Authentication Password: "Password"
where
Password : String (0, 50)
The authentication password.
xConfiguration H323 CallSetup Mode
Defines whether to use a Gatekeeper or Direct calling when establishing H.323 calls.
Direct H.323 calls can be made also when H323 CallSetup Mode is set to Gatekeeper.
Requires user role: ADMIN
Default value: Gatekeeper
USAGE:
xConfiguration H323 CallSetup Mode: Mode
where
Mode : Direct/Gatekeeper
Direct: You can only make an H.323 call by dialing an IP address directly.
Gatekeeper: The system uses a Gatekeeper to make an H.323 call. When choosing this
option, the H323 Gatekeeper Address must also be configured.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
