Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 58
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Network [1] IPStack
Select if the system should use IPv4, IPv6, or dual IP stack, on the network interface. NOTE:
After changing this setting you may have to wait up to 30 seconds before it takes effect.
Requires user role: ADMIN
Default value: Dual
USAGE:
xConfiguration Network n IPStack: IPStack
where
n : Index that identifies the network. Range: 1..1
IPStack : Dual/IPv4/IPv6
Dual: When set to Dual, the network interface can operate on both IP versions at the
same time, and can have both an IPv4 and an IPv6 address at the same time.
IPv4: When set to IPv4, the system will use IPv4 on the network interface.
IPv6: When set to IPv6, the system will use IPv6 on the network interface.
xConfiguration Network [1] IPv4 Assignment
Define how the system will obtain its IPv4 address, subnet mask and gateway address. This
setting only applies to systems on IPv4 networks.
Requires user role: ADMIN
Default value: DHCP
USAGE:
xConfiguration Network n IPv4 Assignment: Assignment
where
n : Index that identifies the network. Range: 1..1
Assignment : Static/DHCP
Static: The addresses must be configured manually using the Network IPv4 Address,
Network IPv4 Gateway and Network IPv4 SubnetMask settings (static addresses).
DHCP: The system addresses are automatically assigned by the DHCP server.
xConfiguration Network [1] IPv4 Address
Define the static IPv4 network address for the system. Applicable only when Network IPv4
Assignment is set to Static.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Network n IPv4 Ad d ress: "Address"
where
n : Index that identifies the network. Range: 1..1
Address : String (0, 64)
A valid IPv4 address.
xConfiguration Network [1] IPv4 Gateway
Define the IPv4 network gateway address. Applicable only when the Network IPv4 Assignment
is set to Static.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Network n IPv4 Gateway: "Gateway"
where
n : Index that identifies the network. Range: 1..1
Gateway : String (0, 64)
A valid IPv4 address.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
