D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 95
Cisco TelePresence MX700 and MX800
API Reference Guide
Call commands
xCommand Call Accept
Accept an incoming call. If no CallId is specified, all incoming calls are accepted.
Requires user role: USER
USAGE:
xCommand Call Accept [Ca llId: CallId]
where
CallId: Integer (0..65534)
The CallID is returned when the xCommand Dial command is run. During the call you
can run the xStatus Call command to see the CallId.
xCommand Call DTMFSend
Send DTMF tones to the far end.
Requires user role: USER
USAGE:
xCommand Call DTMFSend [CallId: CallId] DTMFString: "DTMFString"
where
CallId: Integer (0..65534)
The CallID is returned when the xCommand Dial command is run. During the call you
can run the xStatus Call command to see the CallId.
DTMFString: String (0, 32)
Enter the DTMF string.
xCommand Call Disconnect
Disconnect a call.
Requires user role: USER
USAGE:
xCommand Call Disconnect [CallId: CallId]
where
CallId: Integer (0..65534)
The CallID is returned when the xCommand Dial command is run. During the call you
can run the xStatus Call command to see the CallId.
xCommand Call FarEndControl Camera Move
Move the far end camera (the remote camera).
NOTE: The far end camera moves in the specified direction until the stop command (ref:
xCommand FarEndControl Camera Stop) is issued.
Requires user role: USER
USAGE:
xCommand Call FarEndControl Camera Move [CallId: CallId] Value: Value
where
CallId: Integer (0..65534)
The CallID is returned when the xCommand Dial command is run. During the call you
can run the xStatus Call command to see the CallId.
Value: Left/Right/Up/Down/ZoomIn/ZoomOut
Select the action for how to move the camera.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xCommand

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
