D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 70
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Provisioning HttpMethod
Select the HTTP method to be used for the provisioning.
Requires user role: ADMIN
Default value: POST
USAGE:
xConfiguration Provisioning HttpMethod: HttpMeth od
where
HttpMethod
: GET/POST
GET: Select GET when the provisioning server supports GET.
POST: Select POST when the provisioning server supports POST.
xConfiguration Provisioning ExternalManager Address
Define the IP Address or DNS name of the external manager / provisioning system.
If an External Manager Address (and Path) is configured, the system will send a message to this
address when starting up. When receiving this message the external manager / provisioning
system can return configurations/commands to the unit as a result.
When using CUCM or TMS provisioning, the DHCP server can be set up to provide the external
manager address automatically (DHCP Option 242 for TMS, and DHCP Option 150 for CUCM).
An address set in the Provisioning ExternalManager Address setting will override the address
provided by DHCP.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Provisioning ExternalManager Address: "Addre ss"
where
Address
: String (0, 64)
A valid IPv4 address, IPv6 address or DNS name.
xConfiguration Provisioning ExternalManager AlternateAddress
Only applicable when the endpoint is provisioned by Cisco Unified Communication Manager
(CUCM) and an alternate CUCM is available for redundancy. Define the address of the alternate
CUCM. If the main CUCM is not available, the endpoint will be provisioned by the alternate
CUCM. When the main CUCM is available again, the endpoint will be provisioned by this CUCM.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Provisioning ExternalManager AlternateAddress: "AlternateAddress"
where
AlternateAddress
: String (0, 64)
A valid IPv4 address, IPv6 address or DNS name.
xConfiguration Provisioning ExternalManager Protocol
Define whether to use the HTTP (unsecure communication) or HTTPS (secure communication)
protocol when sending requests to the external manager / provisioning system.
The chosen protocol must be enabled in the NetworkServices HTTP Mode setting.
Requires user role: ADMIN
Default value: HTTP
USAGE:
xConfiguration Provisioning ExternalManager Protocol: Prot ocol
where
Protocol
: HTTPS/HTTP
HTTPS: Send requests via HTTPS.
HTTP: Send requests via HTTP.
