D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 67
Cisco TelePresence MX700 and MX800
API Reference Guide
Peripherals configuration
xConfiguration Peripherals Profile TouchPanels
Define the number of touch panels that are expected to be connected to the video system.
This information is used by the video system's diagnostics service. If the number of connected
touch panels does not match this setting, the diagnostics service will report it as an inconsis-
tency. Note that only one Cisco Touch controller is supported in this version.
Requires user role: ADMIN
Default value: Minimum1
USAGE:
xConfiguration Peripherals Profile TouchPanels: TouchPanels
where
TouchPanels : NotSet/Minimum1/0/1/2/3/4/5
NotSet: No touch panel check is performed.
Minimum1: At least one touch panel should be connected to the video system.
0-5: Select the number of Touch controllers that are expected to be connected to the
video system.
Phonebook configuration
xConfiguration Phonebook Server [1] ID
Define a name for the external phone book.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Phonebook Server n ID: "ID"
where
ID : String (0, 64)
The name for the external phone book.
xConfiguration Phonebook Server [1] Type
Select the phonebook server type.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Phonebook Server n Ty pe: Type
where
Type : Off/VCS/TMS/CUCM
Off: Do not use a phonebook.
VCS: The phonebook is located on the Cisco TelePresence Video Communication
Server.
TMS: The phonebook is located on the Cisco TelePresence Management Suite server.
CUCM: The phonebook is located on the Cisco Unified Communications Manager.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
