Cisco TelePresence MX700 and MX800
API Reference Guide
xCommand UserInterface Message Prompt Display
Display a small window on screen with a title, text and up to five options for response from the
user. The message is displayed on screen until the user gives a response, or until the system
receives the following command xCommand Message Prompt Clear.
Use the xFeedback commands to monitor the feedback from the user. Read more about the
xFeedback commands in the API introduction section in this guide.
Title:
Text:
FeedbackId:
Option.1 to Option.5:
Requires user role: ADMIN
USAGE:
xCommand UserInterface Message Prompt Display [Title: "Title"] Text: "Text"
[Feed backId: "FeedbackId"] [O ption.1: "O p tio n.1"] [O pt ion.2: "Option.2"] [O pt io n.3:
"O ption.3"] [O p t io n.4: "O p t io n.4 "] [O pt io n.5: "Option.5"]
where
Title: String (0, 255)
Enter the message title.
Text: String (0, 255)
Enter the text line to be displayed. The <p> and <br> HTML tags will result in line breaks
as normal; any other tags will appear as plain text.
FeedbackId: String (0, 255)
To identify the feedback enter a FeedbackId.
Option.1: String (0, 255)
Enter the text to appear on the feedback options.
Option.2: String (0, 255)
Enter the text to appear on the feedback options.
Option.3: String (0, 255)
Enter the text to appear on the feedback options.
Option.4: String (0, 255)
Enter the text to appear on the feedback options.
Option.5: String (0, 255)
Enter the text to appear on the feedback options.
xCommand UserInterface Message Prompt Response
Give a response to the xCommand Message Prompt Display.
Use the xFeedback commands to monitor the feedback from the user. Read more about the
xFeedback commands in the API introduction section in this guide.
Requires user role: USER
USAGE:
xCommand UserInterface Message Prompt Response [FeedbackId: "FeedbackId"]
OptionId: OptionId
where
FeedbackId: String (0, 255)
The FeedbackId corresponds to the FeedbackId given by the xCommand Message
Prompt Display command.
OptionId: Integer (1..5)
The OptionId corresponds to the OptionIds given as possible responses in the
xCommand Message Prompt Display command.
xCommand UserInterface Message TextLine Clear
Clears the text line which was defined by the xCommand Message TextLine Display command.
Requires user role: USER
USAGE:
xCommand UserInterface Message TextLine Clear
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xCommand

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
