Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 45
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Cameras Camera [1..7] Gamma Mode
This setting enables gamma corrections, and applies only to cameras which support gamma
mode. Gamma describes the nonlinear relationship between image pixels and monitor
brightness.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras Camera n Gamma Mode: Mode
where
Mode : Auto/Manual
Auto: Auto is the default and the recommended setting.
Manual: In manual mode the gamma value is changed with the gamma level setting, ref.
Cameras Camera [n] Gamma Level.
xConfiguration Cameras Camera [1..7] Gamma Level
By setting the Gamma Level you can select which gamma correction table to use. This setting
may be useful in difficult lighting conditions, where changes to the brightness setting does
not provide satisfactory results. Requires the Cameras Camera [n] Gamma Mode to be set to
Manual.
Requires user role: USER
Default value: 0
USAGE:
xConfiguration Cameras Camera n Gamma Level: Level
where
Level : Integer (0..7)
Define the gamma level.
xConfiguration Cameras Camera [n..7] Mirror
This setting applies to Camera [2..7] for single camera systems, and to HDMI [3..7] for dual
camera systems.
With Mirror mode (horizontal flip) you can mirror the image on screen. Mirroring applies both to
the self-view and the video that is transmitted to the far end.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras Camera n Mirror: Mirror
where
Mirror : Auto/Off/On
Auto: If the camera detects that it is mounted upside down, the image is automatically
mirrored. If the camera cannot auto-detect whether it is mounted upside down or not,
the image is not changed.
Off: Display the image as other people see you.
On: Display the image as you see yourself in a mirror.
xConfiguration Cameras Camera [1..7] Whitebalance Mode
Define the camera white balance mode.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras Camera n Whitebalance Mode: Mode
where
Mode : Auto/Manual
Auto: The camera will continuously adjust the white balance depending on the camera
view.
Manual: Enables manual control of the camera white balance. The white balance level is
set using the Cameras Camera [n] Whitebalance Level setting.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
