Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 36
Cisco TelePresence MX700 and MX800
API Reference Guide
Audio configuration
xConfiguration Audio DefaultVolume
Define the default volume for the speakers. The volume is set to this value when you switch
on or restart the video system. Use the Touch controller to change the volume while the video
system is running. You may also use API commands (xCommand Audio Volume) to change the
volume while the video system is running, and to reset to default value.
Requires user role: USER
Default value: 50
USAGE:
xConfiguration Audio D efaultVolu me: DefaultVolum e
where
Defa ultVolu m e : Integer (0..100)
Select a value between 1 and 100. This corresponds to the dB range from -34.5 dB to
15 dB, in steps of 0.5 dB). If set to 0 the audio is switched off.
xConfiguration Audio SoundsAndAlerts RingTone
Define which ringtone to use for incoming calls.
Requires user role: USER
Default value: Sunrise
USAGE:
xConfiguration Audio SoundsAndAlerts RingTone: RingTone
where
RingTone : Sunrise/Mischief/Ripples/Reflections/Vibes/Delight/Evolve/Playful/Ascent/
Calculation/Mellow/Ringer
Select a ringtone from the list.
xConfiguration Audio SoundsAndAlerts RingVolume
Define the ring volume for incoming calls.
Requires user role: USER
Default value: 30
USAGE:
xConfiguration Audio SoundsAndAlerts RingVolu me: Ring Volume
where
RingVolume : Integer (0..100)
The value goes in steps of 5 from 0 to 100 (from -34.5 dB to 15 dB). Volume 0 = Off.
xConfiguration Audio Input HDMI [n] Level
This setting applies to HDMI [2..3] for single camera systems, and to HDMI [3] for dual camera
systems.
Define the audio level of the HDMI input connector, in steps of 1 dB.
Requires user role: ADMIN
Default value: 0
USAGE:
xConfiguration Audio Input HDMI n Level: Level
where
Level : Integer (-24..0)
Select a value between -24 and 0, in steps of 1 dB.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
