D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 55
Cisco TelePresence MX700 and MX800
API Reference Guide
Network configuration
xConfiguration Network [1] DNS Domain Name
The DNS Domain Name is the default domain name suffix which is added to unqualified names.
Example: If the DNS Domain Name is "company.com" and the name to lookup is
"MyVideoSystem", this will result in the DNS lookup "MyVideoSystem.company.com".
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Network n DNS Domain Na me: "Name"
where
n : Index that identifies the network. Range: 1..1
Name : String (0, 64)
The DNS domain name.
xConfiguration Network [1] DNS Server [1..3] Address
Define the network addresses for DNS servers. Up to three addresses may be specified. If the
network addresses are unknown, contact your administrator or Internet Service Provider.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Network n DNS Server m Add ress: "Address"
where
n : Index that identifies the network. Range: 1..1
m : Index that identifies the DNS server. Maximum three DNS servers are allowed. Range: 1..3
Address : String (0, 64)
A valid IPv4 address or IPv6 address.
xConfiguration Network [1] IEEE8021X Mode
The system can be connected to an IEEE 802.1X LAN network, with a port-based network
access control that is used to provide authenticated network access for Ethernet networks.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Network n IEEE8021X Mode: Mode
where
n : Index that identifies the network. Range: 1..1
Mode : Off/On
Off: The 802.1X authentication is disabled (default).
On: The 802.1X authentication is enabled.
xConfiguration Network [1] IEEE8021X TlsVerify
Verification of the server-side certificate of an IEEE802.1x connection against the certificates in
the local CA-list when TLS is used. The CA-list must be uploaded to the video system. This can
be done from the web interface.
This setting takes effect only when Network [1] IEEE8021X Eap Tls is enabled (On).
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Network n IEEE8021X TlsVerify: TlsVerify
where
n : Index that identifies the network. Range: 1..1
TlsVerify : Off/On
Off: When set to Off, TLS connections are allowed without verifying the server-side
X.509 certificate against the local CA-list. This should typically be selected if no CA-list
has been uploaded to the codec.
On: When set to On, the server-side X.509 certificate will be validated against the local
CA-list for all TLS connections. Only servers with a valid certificate will be allowed.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
