D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 47
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Cameras SpeakerTrack ConnectorDetection Mode
Not applicable in this version.
USAGE:
xConfiguration Cameras SpeakerTrack ConnectorDetection Mode: Mode
where
xConfiguration Cameras SpeakerTrack ConnectorDetection CameraLeft
Not applicable in this version.
USAGE:
xConfiguration Cameras SpeakerTrack ConnectorDetection CameraLeft: CameraLeft
where
xConfiguration Cameras SpeakerTrack ConnectorDetection CameraRight
Not applicable in this version.
USAGE:
xConfiguration Cameras SpeakerTrack ConnectorDetection Ca meraRight: CameraRight
where
xConfiguration Cameras SpeakerTrack Whiteboard Mode
This setting applies to systems with a dual camera (speaker track).
Define whether to enable the Snap to Whiteboard feature or not.
The Snap to Whiteboard feature relies on a speaker track camera. When a presenter is stand-
ing next to the whiteboard, the camera will capture both the presenter and the whiteboard if
the Snap to Whiteboard feature is enabled. If the feature is disabled, only the presenter will be
captured.
The Snap to Whiteboard feature is set up from the Touch controller.
Requires user role: USER
Default value: Off
USAGE:
xConfiguration Cameras SpeakerTrack Whiteboard Mode: Mode
where
Mode
: Off/On
Off: The Snap to Whiteboard feature is disabled.
On: The Snap to Whiteboard feature is enabled.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus
xConfiguration

Table of Contents

Other manuals for Cisco Telepresence MX800

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco Telepresence MX800 and is the answer not in the manual?

Cisco Telepresence MX800 Specifications

General IconGeneral
Pan range-90 - 60 °
Product typeVideo conferencing service management system
Product colorWhite
Wall mountableYes
Tilt angle range-14 - 12 °
Number of persons- person(s)
Aspect ratio16:9
Maximum frame rate60 fps
Supported video modes720p, 1080p
Video formats supportedH.261, H.263, H.264, H.265
Resolution at capture speed1920x1080@60fps
Supported graphics resolutions352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel- MP
Sensor type-
Digital zoom2 x
Optical zoom10 x
Image sensor size- \
Closest focusing distance1 m
Ethernet LAN data rates10, 100, 1000 Mbit/s
Display diagonal70 \
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (max)591 W
Power consumption (typical)571 W
