Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 41
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Audio Input Microphone [1..8] Mode
Define the audio input microphone mode.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Audio Input Microphone n Mode: Mode
where
Mode : Off/On
Off: Disable the audio input microphone connector.
On: Enable the audio input microphone connector.
xConfiguration Audio Input Microphone [1..8] Type
The microphone connectors are intended for electret type microphones. The microphone
connector can be set to line or microphone mode.
Requires user role: ADMIN
Default value: Line
USAGE:
xConfiguration Audio Input Microphone n Ty pe: Type
where
Type : Line/Microphone
Microphone: Select Microphone when you have 48 V Phantom voltage and the
pre-amplification is On.
Line: Select Line when you have a standard balanced line input. The phantom voltage
and pre-amplification is Off.
xConfiguration Audio Output HDMI [2] Level
This setting only applies to MX800 Single.
Define the output level of the HDMI output connector, in steps of 1 dB.
Requires user role: ADMIN
Default value: 0
USAGE:
xConfiguration Audio Output HDMI n Level: Level
where
Level : Integer (-24..0)
Select a value between -24 and 0, in steps of 1 dB.
xConfiguration Audio Output HDMI [2] Mode
This setting only applies to MX800 Single.
Define if the audio channel on the HDMI output connector shall be enabled.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Audio Output HDMI n Mode: Mode
where
Mode : Off/On
Off: Disable the audio channel on the HDMI output.
On: Enable the audio channel on the HDMI output.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
