Cisco Telepresence MX800 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 118
Cisco TelePresence MX700 and MX800
API Reference Guide
RoomPreset commands
xCommand RoomPreset Activate
Activate one of the locally stored presets.
Note that information about all video input sources, and pan, tilt, zoom and focus values for
all cameras are included in the same preset. In contrast, the xCommand Camera Preset
commands applies to individual cameras only.
Requires user role: USER
USAGE:
xCommand RoomPreset Activate PresetId: PresetId
where
PresetId: In teg er (1..15)
The ID of the preset you want to activate.
xCommand RoomPreset Clear
Delete a preset.
Note that information about all video input sources, and pan, tilt, zoom and focus values for
all cameras are included in the same preset. In contrast, the xCommand Camera Preset
commands applies to individual cameras only.
Requires user role: USER
USAGE:
xCommand RoomPreset Clear PresetId: PresetId
where
PresetId: In teg er (1..15)
The ID of the preset you want to delete.
xCommand RoomPreset Store
Store the connector selections for all video input sources and the current position (pan and tilt),
zoom and focus values for all cameras.
Note that information about all video input sources, and pan, tilt, zoom and focus values for
all cameras are included in the same preset. The system may hold 15 such predefined video
input presets. These presets are available for far end control, i.e. they are referred in the
PresetId parameter of the xCommand FarEndControl Preset Activate command. In contrast, the
xCommand Camera Preset commands applies to individual cameras only. Those presets are
not available for far end control.
Requires user role: USER
USAGE:
xCommand RoomPreset Store [Description: "Des cription"] PresetId: PresetId Ty pe:
Type
where
Description: String (0, 255)
Enter a description of the camera preset.
PresetId: In teg er (1..15)
The ID of this preset.
Type: All/Camera
Not applicable. If you want to ensure that a preset only affects camera positions we
recommend that you select Camera.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xCommand

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
