D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 56
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Network [1] IEEE8021X UseClientCertificate
Authentication using a private key/certificate pair during an IEEE802.1x connection. The authen-
tication X.509 certificate must be uploaded to the video system. This can be done from the
web interface.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Network n IEEE8021X UseClientCertificate: UseClientCertificate
where
n : Index that identifies the network. Range: 1..1
UseClientCertificate : Off/On
Off: When set to Off client-side authentication is not used (only server-side).
On: When set to On the client (video system) will perform a mutual authentication TLS
handshake with the server.
xConfiguration Network [1] IEEE8021X Identity
Define the user name for 802.1X authentication.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Network n IEEE8021X Identity: "Identity"
where
n : Index that identifies the network. Range: 1..1
Identity : String (0, 64)
The user name for 802.1X authentication.
xConfiguration Network [1] IEEE8021X Password
Define the password for 802.1X authentication.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Network n IEEE8021X Password: "Password"
where
n : Index that identifies the network. Range: 1..1
Password : String (0, 32)
The password for 802.1X authentication.
xConfiguration Network [1] IEEE8021X AnonymousIdentity
The 802.1X Anonymous ID string is to be used as unencrypted identity with EAP (Extensible
Authentication Protocol) types that support different tunneled identity, like EAP-PEAP and
EAP-TTLS. If set, the anonymous ID will be used for the initial (unencrypted) EAP Identity
Request.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration Network n IEEE8021X AnonymousIdentity: "AnonymousIdentity"
where
n : Index that identifies the network. Range: 1..1
AnonymousIdentity : String (0, 64)
TThe 802.1X Anonymous ID string.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco Telepresence MX800 Specifications

General

Pan range	-90 - 60 °
Product type	Video conferencing service management system
Product color	White
Wall mountable	Yes
Tilt angle range	-14 - 12 °
Number of persons	- person(s)
Aspect ratio	16:9
Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.263, H.264, H.265
Resolution at capture speed	1920x1080@60fps
Supported graphics resolutions	352 x 288, 512 x 288, 1024 x 576 (WSVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Megapixel	- MP
Sensor type	-
Digital zoom	2 x
Optical zoom	10 x
Image sensor size	- \
Closest focusing distance	1 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Display diagonal	70 \
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	591 W
Power consumption (typical)	571 W
